Pentachoron

A pentachoron is a 4-dimensional simplex. It is also called the pyrochoron under the elemental naming scheme. Its Bowers acronym is "pen".

Symbols[]

The pentachoron can be given by these Dynkin symbols:

x3o3o3o (regular)
ox3oo3oo&#x (tetraherdral pyramid)
xo ox3oo&#x (trigonal disphenoid)
oxo3ooo&#x (triangular scalene)
oxo oox&#xt (disphenoid pyramid)
ooox&#x (line tettene)
ooooo&#x (irregular pen)

Structure and Sections[]

Structure[]

The pentachoron is the pyramid of the tetrahedron, with 4 tetrahedra on each vertex.

Hypervolumes[]

vertex count = $5$

edge length = $10l$

surface area = $\frac { 5\sqrt { 3 } }{ 2 } { l }^{ 2 }$

surcell volume = $\frac { \sqrt { 2 } }{ 3 } { l }^{ 3 }$

surteron bulk = $\frac { \sqrt { 5 } }{ 96 } { l }^{ 4 }$

Subfacets[]

5 points (0D)
10 line segments (1D)
10 triangles (2D)
5 tetrahedra (3D)

Radii[]

Vertex radius: $\frac{\sqrt{10}}{5}l$

Edge radius: $\frac{\sqrt{15}}{10}l$

Face radius: $\frac{\sqrt{15}}{15}l$

Cell radius: $\frac{\sqrt{10}}{20}l$

Angles[]

Dichoral angle: $\arccos(\frac{1}{4})$

Vertex coordinates[]

The verticeds of a pentachoron can best be represented as a facet of the pentacross, as all permutations of (√2,0,0,0,0). The coordinates of a pentachoron in a 4D space can be given by:

(±1,-√3/3,-√6/6,-√10/10)
(0,2√3/3,-√6/6,-√10/10)
(0,0,√6/2,-√10/10)
(0,0,0,2√10/5)

Notations[]

Tapertopic notation: $1^3$

Related shapes[]

Dual: Self dual
Vertex figure: Tetrahedron, side length 1
